| Description | Item No | Unit** | Material | Weight per 100 pcs. | Packaging | Diameter (d) | Thread type | Tensile strength | Length (l) | Diameter of head (dk) | Height of head (k) | Drive shape | Head shape | Drive size | Thread length (b) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Art. 14580 A2 M 8X40/40 TX40 h=5mm Hexalobular socket cheese head screws, serr. | 14580208 40 | 100 | A2 | 1,74 kg | 100 pcs. | 8 mm | Metric | 500 N/mm2 | 40 mm | 13 | 5 | Inner multi-tooth | Cylinder head | TX40 | 40 mm |
| Art. 14580 A2 M 8X42/42 TX40 h=5mm Socket head cap screws, six lobe drive, serration | 14580208 42 | 100 | A2 | 1,80 kg | 100 pcs. | 8 mm | Metric | 500 N/mm2 | 42 mm | 13 | 5 | Inner multi-tooth | Cylinder head | TX40 | 42 mm |
| Art. 14580 A2 M 8X55/55 TX40 h=5mm Socket head cap screws, six lobe drive, serration | 14580208 55 | 100 | A2 | 2,10 kg | 100 pcs. | 8 mm | Metric | 500 N/mm2 | 55 mm | 13 | 5 | Inner multi-tooth | Cylinder head | TX40 | 55 mm |
